EvaLay is Terra Mater's EVA foam underlay, listed for floating floors: engineered timber, laminate and hybrid. It comes in two versions: EvaLay, at 2mm with an 80µm water barrier film, and EvaLay Plus, at 3mm with a heavier 100µm film. Both have a density of 110kg/m³, come in 1m x 20m rolls covering 20m², and Terra Mater's data sheet lists both with a 6-Star acoustic rating, with individual test results of 5 to 6 Star depending on the floor laid over them. Underlay choice affects how a floating floor sounds and feels, so it's worth getting right alongside the floor itself. Note that the ResiPlank hybrids already have an EVA underlay attached to each plank, so we'll tell you whether an additional underlay is needed for the floor you choose. EvaLay is a hard-floor underlay and isn't intended for carpet. We'll recommend the right version as part of your written quote, and we can bring a sample to your home with your flooring choices.
EvaLay Underlay
Price on request. Supply and installation quoted after a free measure.
- Floating engineered timber floors
- Laminate floors
- Hybrid floors without attached underlay
- Apartments (acoustic rating published)
2 colours · Free measure and written quote · Installed by our experienced team · 5.0 from 300+ Google reviews
Choose your colour
Screen colours vary. We always bring real samples so you can see them in your own light.
| Options | EvaLay (2mm) and EvaLay Plus (3mm) |
|---|---|
| Material | EVA foam |
| Thickness | Varies by option: 2mm or 3mm |
| Water barrier film | Varies by option: 80µm (EvaLay) or 100µm (EvaLay Plus) |
| Density | 110kg/m³ |
| Roll size | 1m x 20m (20m²) |
| Acoustic rating | Listed as 6 Star. In the published tests, EvaLay (2mm) rated 6 Star under all four floors tested and EvaLay Plus (3mm) 5 or 6 Star depending on the floor, as listed by the manufacturer |
| Suitable for | Floating engineered timber, laminate and hybrid floors |
EvaLay Underlay FAQs
What's the difference between EvaLay and EvaLay Plus?
EvaLay is 2mm with an 80µm water barrier film; EvaLay Plus is 3mm with a 100µm film. Both are 110kg/m³ EVA in 20m² rolls.
Do I need EvaLay under a ResiPlank hybrid?
ResiPlank hybrid planks have an EVA underlay already attached, and Terra Mater notes its hybrids usually don't need an additional one. We'll confirm at the measure whether anything extra is needed for your floor and subfloor.
Measured and quoted by people who install floors
We bring the samples to your home, measure for free and give you a written quote. Tony has been a professional carpet installer for more than 20 years, and our team has floored thousands of Melbourne homes and businesses since 2010.
